AUDIO INPUT
Connectors Phoenix connector
Wiring IN – (-) IN + (+) GRD (Ground)
POWER INPUT
Connectors Phoenix connector
Wiring VCC (+) GND (common)
AMPLIFIER
Type 1 Module Class D Electronically Processed
Nominal Power Output 32 W @ 8 Ω 1% THD + NOISE
(1 )
Protections
Dynamic limiter, over current, over temperature,
short circuit power supply polarity inversion
Frequency response 20Hz – 20kHz (+/- 3 dB) for 1W @ 8 Ω
THD+N 1kHz,1 W 0,100%
Notes for data
1
. EIAJ Test Standard, 1 kHz, 1%THD
New materials and design are introduced into existing products without previous notice. Present systems may differ in some
respects from those presented in this datasheet.
DC POWER
Nominal voltage 12/24 Vdc
Operating range 10 - 26 Vdc
I. Nom. 0.4 A / 24 Vdc
CONSUMPTION
Efficiency 83%
Nominal power
10 W
PHYSICAL
Dimensions
35 mm x 40 mm x 14 mm
(1,37“ x 1,57” x 0,55 “)
Weight 40 g (0.08 lb)
DesigneD as passive speakers, the new tornaDos can be easily converteD into
self-powereD Devices by inserting the
KA1-T2H ACCESSORY
The contents of this manual are furnished for informational purposes only. K-array s.u.r.l. assumes no responsibility for any errors or inaccuracies that may appear
in this manual. K-array s.u.r.l. reserves the right to make modifications without prior notice.
