K-array Tornado KT2 - Detailed Product Specifications

KT2 - KT2C - KTL2 - KTL2C
12
Ver. 2.3
13. SPECIfICATIoNS
ACOUSTICS
Power handling 18 W
(AES)
Frequency range 150 Hz – 18 kHz (-10dB)
(1)
Impedance 8 Ω / 32 Ω (selectable)
Maximum SPL 101 dB (cont.) – 107 dB (peak)
(2)
COVERAGE
Horizontal 90°
Vertical 90°
CROSSOVER
Type External Crossover required
Frequency
150 Hz, 24 dB/oct
suggested minimum
TRANSDUCERS
Full range
2” Neodymium magnet woofer
with 2 x 0.8” voice coils
POWER AUDIO INPUT
Connector 4-pin Phoenix
RECOMMENDED AMPLIFIERS
Type KA24, KA84
CERTIFICATION
IP 54
PHYSICAL
KT2 KT2C
Dimensions
74 mm x 123 mm x 118 mm
(2.9“ x 4.8” x 4.6“)
125 mm x 125 mm x 119 mm
(4.9“ x 4.9” x 4.7“)
Weight
0.56 kg (1.23 lbs) 0.67 kg (1.48 lbs)
ACOUSTICS
Power handling 18 W
(AES)
Frequency range 150 Hz – 18 kHz (-10dB)
(1)
Impedance 8 Ω / 32 Ω (selectable)
Maximum SPL 101 dB (cont.) – 107 dB (peak)
(2)
COVERAGE
Horizontal 90°
Vertical 90°
CROSSOVER
Type External Crossover required
Frequency
150 Hz, 24 dB/oct
suggested minimum
TRANSDUCERS
Full range
2” Neodymium magnet woofer
with 2 x 0.8” voice coils
POWER AUDIO INPUT
Connector 4-pin Phoenix
RECOMMENDED AMPLIFIERS
Type KA1-T2H, KA24, KA84
LED
Type 7 x RGB LED
Connector 4-pin Phoenix
Light Output
Black version: 330 lumen
White version: 400 lumen
Viewing Angle 90°
Consumption 10 W
CERTIFICATION
IP 40
PHYSICAL
KTL2 KTL2C
Dimensions
74 mm x 123 mm x 118 mm
(2.9“ x 4.8” x 4.6“)
125 mm x 125 mm x 119 mm
(4.9“ x 4.9” x 4.7“)
Weight
0.54 kg (1.2 lbs) 0.59 kg (1.3 lbs)
KT2 - KT2C
KTL2 - KTL2C
Notes for data
1. With dedicated preset;
2. Measured with musical signal
New materials and design are introduced into existing products without previous notice. Present systems may differ in some
respects from those presented in this datasheet.
Notes for data
1. With dedicated preset;
2. Measured with musical signal
New materials and design are introduced into existing products without previous notice. Present systems may differ in some
respects from those presented in this datasheet.
