CD1000 Pin Welder Instruction Manual
K.C.D. Studwelding, Cheltenham, Victoria. Tel: 03 9584 1588, Fax: 03 9584 1688
APPENDIX 2:
SPECIFICATIONS
STUD SIZE .105” insulation pin through 5/32 whit or M4 threaded studs
STUD MATERIAL Copper finished mild steel, stainless steel and brass studs.
Zinc plated and stainless steel pins.
WEIGHT 15 kg.
SIZE 315mm x 436mm x 245mm
WELDING RATE 15 per minute
INPUT POWER 240 V.A.C.
WELD MODE Contact
CIRCUIT
PROTECTION Primary fuses. Output voltage; circuit breaker operator protection.
CABLE LENGTH Gun 4.8m (16’)
Earth 3.04m (10’)
WELD GUN
WEIGHT 0.68 kg (1.5lbs)
SIZE 11.4 cm x 5 cm x 14.9 cm
MATERIAL High strength, impact resistant glass fibre reinforced polycarbonate.
