Kaabo Skywalker 8S - Specification 8 S

05 06
SPECIFICATION 8S
40 km/h
Max. Speed
4 - 6 hCharging
Rear Disc Brake + EABS Electronic Brake
85mm Soild Tire
800 w
Motor
Brake
Tire
N.W
22 kg
Configuraon
48 V
13 AH
40 - 45 km
Max. Range
C Shock Absorpon
1080 x 190 x 350 mm
Shock Absorber
Open Size
1100 x (520 ~560) x 1150 mm
Folding Size
1120 x 260 x 430 mm
Package Size
* The specificaon can be changed by manufacturer to meet the requirements and laws of
different countries and regions.
* The distance can be affected by loaded weight, wind direct (wind speed), riding surface
density, slope and re condion.
PRODUCT DIAGRAM 8S
[1] Handle [2]Light&horn Switch [3] Display
[4] Folding Lever [5] T Bar [6] Lock Nut
[7] Main Tube [8] Light&Horn [9] Protecon Pin
[10] Shock Absorber [11] Pedal [12] Rear Light
[13] 8” Tire [14] Kickstand [15] Motor
[2]
[5]
[4]
[3]
[6]
[8]
[11]
[9]
[12]
[1]
[15]
[14]
[10]
[13]
[7]
