Kaabo Skywalker 8S - Specification 10

07 08
SPECIFICATION 10
38 km/h 42 km/h
Max. Speed
3 - 5 h 6 - 8 h 4 - 6 hCharging
Front and Rear Disc Brake + Electronic Brake
10.0 x 2.25 / 10.0 x 2.5 res
400 w 500 w
Motor
Brake
Tire
N.W
17.3 kg 19.3 kg 18.6 kg
Configuraon
36 V
10.4 AH
36 V
21 AH
48 V
15.6 AH
28 - 32 km 65 - 70 km 50 - 55 km
Max. Range
No
1120 x 240 x 360 mm
Shock Absorber
Open Size
1135 x 560 x 1200 mm
Folding Size
1200 x 300 x 450 mm
Package Size
* The specificaon can be changed by manufacturer to meet the requirements and laws of
different countries and regions.
* The distance can be affected by loaded weight, wind direct (wind speed), riding surface
density, slope and re condion.
PRODUCT DIAGRAM 10
[1] Handle [2] Light&horn Switch [3] Display
[4] Folding Lever [5] T Bar [6] Lock Nut
[7] Main Tube [8] Light&Horn [9] protecon pin
[10] Shock Absorber [11] Pedal [12] Rear Light
[13] 10” Tire [14] Kickstand [15] Motor
[2]
[5]
[4]
[3]
[6]
[8]
[11]
[9]
[12]
[1]
[15]
[14]
[10]
[13]
[7]
