G4
lodging-tech@kaba-ilco.com
1-800-906-4526
Sign up for our Technical Support Website http://connect.kabalodging.com/
PC – PMS INTERFACE
LRC = 2
Virtual Com4
1 address
TCP-COM
connector: Com4
baud: 9600
parity: none
data bits: 8
stop bit: 1
flow control: none
buffer size: 8192
create virtual com port
remote host IP address:
192.168.001.100
remote port:
10001
Required software TCP-COM
to enable RS232 communication to an IP address.
GATEWAY II – MOXA BOX SETUP
PRESS F5 MENU
PRESS F1 CONFIG:
PRESS F3 PMS = F1 PORT = LAN1
P8 = N/A
PRESS F1 NETWORK MODE-DHCP
IP ADDRESS = 192.168.001.100
SUBMASK= 255.255.255.000
PC/PMS
INTERFACE
Router
RJ45
NETWORK
RJ45
RJ45
LAN1
GATEWAY II
GATEWAY II WITH LAN1 CONNECTION
