3
RFID Wall Reader Installed with ILCO RAC 4 or RAC4XT Installation Guide - PK3660_07_16
Controller
Board
124-511689-002
123
Bypass
Active
Reset
SW1
SW2
D46
D45
D41
D42
J1 J2 J3
J5
J6
J7
J8
J9
J12J13J14
J15
J16
J17
J18
J19
D43
D44
Programming
Port
SW3
WHITE
GREEN
E
BLACK
RED
ON
123 123
123123 123 121234
1 23
4 123 4 123 4
123 123 4
123 4
For EGRESS
Application
RED
For INGRESS
Application
See Note 1*
Controller Board to RFID Wall Mounted Reader Connection
RAC4/4XT Controller Board Connection
Signal Reader Connection
GND J4 - 2 J1, Pin 2 J14, Pin 2
+12V J4 - 1 J1, Pin 3 J14, Pin 3
RS485+ J5 - 2 J2, Pin 1 + J3, Pin 1* J13, Pin 1 + J12, Pin 1
RS485- J5 - 1 J2, Pin 2 + J3, Pin 2* J13, Pin 2 + J12, Pin 2 Green See Note
Note: Jumper cables as shown in figure B must be connected for the reader to operate correctly.
Wire Color
Red
Black
See NoteWhite
Comments
GND
+12V
Ingress Reader
Terminal Block
Egress Reader
Figure B: RAC 4XT Controller Board
(Note: RAC 4 Ingress only)
Figure A: RFID Wall Mounted Reader
Instructions
1. Use drilling template provided to prepare surface for installation
2. Route the wire to the rac 4/4xt enclosure and connect to the controller board as per the column “RAC 4/4XT Controller
Board Connection” in table 1, or as per Figure B
3. Route the other end of the wire through the hole in the mouting plate to the back of the reader and connect as per column
“Reader Connection” in table 1 or as per Figure A
Important: The jumper cables supplied with the reader must be connected as shown in Figure B and Table 1 for the contactless
reader to operate properly.
Note: The RAC 4 controller board supports a single reader only, for ingress functionality, using connectors J1 and J2.
Note: The rac 4XT controller board can support dual readers for ingress (Connectors J1 & J2) and egress (Connectors J13 &
J14) functionality.
Table 1: RAC 4/4XT RFID Wall Mounted Reader Wire Connections
RFID Wall Reader Instructions - (All Models)
BLUETOOTH (BLE)
CONNECTOR
To Next Page
