21
F01 KAFAS
Signal path for controlling the vibration actuator
Control of the vibration actuator in the steering wheel is initiated by the KAFAS control
unit in interaction with the ZGM, ICM and SZL.
The ICM is always included in the control of the vibration actuator so that, in vehicles
equipped with both the optional lane change warning and the lane departure warning, the
driver is able to distinguish between the warnings of these similar systems.
Control of the lane departure warning vibration actuator in the F01/F02
Index Explanation Index Explanation
KAFAS
KAFAS control unit
SZL
Steering column switch cluster
ZGM
Central gateway module
ICM
Integrated Chassis Management
