System overview of KAFAS components legend
Index Explanation Index Explanation
1
Lane departure warning/High-beam assistant
forward-pointing video camera
10
Instrument cluster
Function display
2
KAFAS control unit
(Equipment specification with lane
departure warning, evaluation of image data)
11
Head-up display (HUD)
Function display
3
Driver assistance systems operating unit
Lane Departure Warning on/off button
12
Controller
4
Footwell module (FRM)
High-beam headlights on/off
13
Car Information Computer (CIC)
navigation system, navigation system data
5
Light switch
(High-beam assistant function in
position A or position II)
14
Central Information Display (CID)
6
High-beam assistant on/off button on the turn
signal stalk on the steering column
15
Junction box electronics
7
Steering column switch cluster (SZL) with turn
signal stalk on the steering column
16
Front distribution box
8
Integrated Chassis Management (ICM)
Road-speed signal
17
Car Access System (CAS)
9
Central gateway module (ZGM)
