6
NOTE:
1. The HDMI Slide Switch much be switched to off if you want to output
RGBS/Component signals through the Saturn AV Connector.
2. The GBSC only outputs lower resolutions such as 240p/288p through the
Saturn AV Connector.
VGA OUTPUT:
Standard D-Sub15 (VGA) connector.
NOTE:
If you want to output VGA signals through this interface, The “HDMI SLIDE
SWITCH” must be turned to “OFF”.
HDMI SLIDE SWITCH:
Toggles the HDMI signal OFF and ON.
RGBHV/RGBS SLIDE SWITCH:
If you want to output RGBS signal, please slide this switch to “RGBS” side. In
other cases, please keep RGBHV by default.
NOTE:
This function is used as RGBHV (VGA) to RGBS signal output.
SCART INPUT:
The European standard SCART interface can only receive RGBS signals.
The less common Japanese JP21 SCART must be used with a converter.
VGA INPUT:
Standard D-Sub15 (VGA) connector, accepts the VGA and RGBHV signals.
It can also receive RGsB signals.
NOTE:
If you use this interface, you must press down the switch ”SYNC ON GREEN
SELF-LOCKING BUTTON”.
COMPONENT INPUT:
Accepts the Component (YPBPR) signal.
NOTE:
The “SYNC ON GREEN SELF-LOCKING BUTTON” and “RGBS SYNC
SELF-LOCKING BUTTON” must stay pressed in.
AUDIO INPUT:
Left and right audio input.
To Next Page
