14
EN
NSTALLATION OF THE HOBS
The regulations covering the installation,
maintenance and operation of gas appliances for
domestic use are applicable regulations.
This appliance is not provided with a combustion
product discharge.
Installation and connection should be made in
accordance with this regulation.
It is recommended that it be installed in sufficiently
aerated places, in terms of the laws in force.
The quantity of air which is necessary for
combustion must not be below 2,0 m³/h for each
kW of installed power (See «Nozzle table»).
The appliance can be fitted into a working area as
illustrated on the corresponding figure.
The installation space measurements are given in
mm.
Make sure that surrounding materials are heat
resistant.
Apply the seal provided over the whole of the area
perimeter.
min 55
min 15
min 600
min 150
min 650
min 150
