17. Frames – the CD player breaks down a second into 75 frames for accurate cueing.
This shows the frames elapsed or remaining depending on mode setting.
18. Mode display – shows the sound effect name, or MP3 file name /Folder. Folder name can not be displayed.
19. Pitch – lights to indicate the pitch value is under it.
20. Prog – lights to indicate that there is a program list in normal playback. Blinks when the program list is active.
21. MT – lights up when performing master tempo function.
22. Reloop – lights up when performing the loop function.
23. 000 – shows the BPM value.
24. BPM – illuminates when the power is on.
25. Auto – lights up when AUTO BPM function is activated.
Techinical specifications
Quantization 1 bit linear/channel, 3 beam laser
Oversampling rate 8 times
Sampling Frequency 44.1KHz
Frequency response 20Hz to 20KHz ±2dB
T.H.D. + NOISE less than 0.03%
S/N ratio (IHF-A > 75 dB
Dynamic range > 75 dB
Output level 1.0 volts R.M.S. ±0.2V
Disc Type Standard compact discs, audio CD, CD-R & MP3 CD-ROM (MP3 files)
USB Ports USB
Time Display Track elapsed, track remain, or total remain
Text Mode Text mode – displays CD-TEXT and ID3 tag information.
Pitch control range ± 8, 16, 100% slider
MP3 format
DISC DISC/USB USB Devices
Applicable file extensions .MP3 .mp3 .Mp3 .mP3
File systems compatible ISO9660 FAT , NTFS , HFS+
CD-ROM sector / HD capacity Mode-1, Mode-2 Max. 2000 Gigabyte
Folder / directory level max. 8 levels down
Max. number of partitions max. 16 partitions
Max. number of folders max. 999 folders
Max. number of files max. 999 files
MP3 format MPEG1 layer3 32-320kbps, f/s 32K 44.1K 48K ,
MPEG2 layer3 40-1600kbps, f/s 16K 22.05K 24K ,
Encoding (VBR/CBR)
ID3 Tag Ver. : V1.0 , V1.1 , V2.2 , V2.3 ,V2.4
GENERAL
Power requirements AC 230V, 50Hz
Power consumption 20w
Operating temperature +5˚C – +35˚C
Dimensions (mm) 427(L) x 345(W) x 221(H)
