3. Equipment
4. Machine
The machine is partially disassembled when it is
delivered and is packed in a cardboard package
(box). The conditions to which the package must
not be subject are listed outside the package.
Do not overturn or lay the package to
the side, always keep it vertical.
The standard equipment includes: instruction
manual, warranty certificate, vise, bandsaw blade
(75” x 3/4” x .035”) already installed.
Upon delivery of the equipment, check (visually) in
the presence of the transporter, that there are no
traces of “difficult” transportation which may raise
doubts as to the intactness of its content. In this
case, open the box immediately and check that the
equipment is perfectly intact.
3.1 Warranty
The machine is guaranteed for six months following
the date of purchase: the warranty is valid only if all
of the instructions listed on the warranty certificate
and in this manual are fully complied with.
3.2 Handling the package
Note. The packaging weight and volume require the
involvement of two people.
Dimensions and weight:
L = 38” W=22” H=31” Lbs.=225
When unpacking the machine make sure
the machine is in perfect condition and
that the package contains the parts
described; the Manufacturer shall not be
responsible for errors or missing parts following
five days after shipment.
The packing material must be disposed of
according to environmental protection
regulations.
4.1 General Description
" The sawing machine EV 996 is designed and
built for cutting operations (separations in two
parts) of metal pieces of any nature (pipes, bars,
sections, etc.)
" The machine is equipped with blade and
automatic cooling system by emulsifiable oil.
" The blade provided has bi-metal features. For
specific uses, it is recommended replacing it with
a more suitable blade.
" The “dry” or “cooled” cut is in accordance with
the type of material on the basis of its
dimensions and its section. Thus, the choice of
the operative mode is left to the experience of the
operator or other specially designated personnel.
" The machine can be used for cuts ranging from
0° to 45°, in compliance with the limits and
environmental condition, recommended by the
Manufacturer or safety and health rules in force.
This machine is suitable for cutting
wood, soft plastic materials, animal
bones, etc.
Any maintenance operation except for
those specifically described in the pages
of this manual, must be carried out by
skilled personnel co-ordinated directly
by the authorized Technical Service.
3.3 Assembly (fig. 1)
" Once the packaging has been removed, the
machine arrives in two parts: the base is
positioned on the operating unit, thus reducing
the overall cubage to half and protecting in
transit.
" Remove the base (1) (it acts as cover in this
configuration) and lay it on the ground.
" Fit the rear guard (it is positioned loose in the
packaging) by fastening it with the screws
supplied.
" Raise (two people involved) and position the
operating unit on the base edge and fasten it with
the four screws (A fig.1) supplied.
" Insert and fasten (with the appropriate screw
without head) the guide rod (B) of the piece
holder (3).
" Insert the piece holder (3) on the rod and lock it
by the knob (4).
