For any information and/or technical explanations
regarding the machine, always indicate:
" model;
" serial number;
" edition and preparation date of the instruction
manual.
The description includes the use for
which the product has been designed,
failure to comply with the technical
parameters listed below may constitute
a hazard to people and/or property.
4.2 Identification
Machine identification information shown on the
plate (G fig. 1): Manufacturer - Serial number -
Model - Year of Manufacture - Electric voltage
(Volt) - Frequency (Hz) - Electrical power (Kw) -
Electrical input (A) - Weight (kg.)
It is strictly forbidden to remove or
damage the plates on the machine.
4.3 Components (fig. 1)
1. Base
2. Liquid Tank
3. Piece Holder
4. Piece Clamp
5. Machine Body
6. Saw Tension Lever
7. Grip (on/off)
8. Control Panel
9. Cutting Speed Regulator
10. Blade Guide Lock Lever
11. Blade Guide
12. Band Saw Blade
13. Electric Motor
14. 90° Rotation Unit
15. Cooling Liquid Pump
16. Cooling Liquid Taps
4.4 Technical Specifications
" Blade Drive Pulleys: on Bearings
" Transmission: treated, Tempered Steel Gears
" Switch with safety device
" Automatic Blade Tensioner
" Maximum cutting capacity: 6.75”
" Standard Blade:
- material: M42 - HSS
- length: 75”
- height: 3/4”
- thickness: .035”
- teeth 6-10 variable tooth
4.5 Selection: Blade Cutting Speed
Table 3 shows some examples of the most
common cutting conditions. The choice of the
type of blade and the cutting speed is in
accordance with the type of material and its
section. Table 4 (below) shows the machine
capacity according to cutting angles.
Cutting Capacity:
Table 4
90° 45°
• 6.75” 4.9”
¶ 6.75” 4.9”
¿ 6.75” x 5.9” 4.3” x 6.75”
4.6 Technical Features
Electric Voltage: 110 Volt - 60 Hz - Single Phase
220 Volt - 60 Hz - 1 or 3 Phase
(See nameplate to determine
Voltage and single or 3 phase).
Overall installed power: Watt 1200/2400
Insulation Class: F
Emulsifiable oil (5% + 8%): MOBIL HYDROIL
Cooling liquid tank capacity: 3 gallons
Speed: 105/210 ft./minute
Loadless Weight: 225 pounds
4.7 Overall dimensions
L 37”
W 21”
H 51”
