- If the generator often operates at high temperature or high load, the oil should be replaced every 25 operating hours.
- If the engine often runs in dusty or other harsh conditions, clean the air filter every 10 operating hours.
- If you missed the maintenance time, perform it as soon as possible to save the generator engine.
The manufacturer shall not be liable for any damage caused by
failure to perform maintenance work.
IMPORTANT!
RECOMMENDED OILS
11
Upon oil level decrease it is necessary to add the required quantity in order to provide the correct generator opera-
tion. It is necessary to check the oil levels according to technical maintanance schedule.The detailed description of oil
lling and draining can be found in the full version of the manual.
Use oils designed for four-stroke cycle vehicle engines
SAE10W-30, SAE10W-40. Motor oils with other viscosity levels,
may be used only if the average air temperature in your region
does not exceed the limits of the temperature range, specified
in the table.
0
00
CC
10W-30, 10W-40
4040303020201010-10-10-20-20
AIR FILTER TECHNICAL MAINTENANCE
12
Air filter cleaning is to be performed each 50 hours of the generator operation (every 10 hours in unusually dusty
conditions).
CLEANING THE FILTER CLEANING THE FILTER (FIG.1 IN THE ANNEX)(FIG.1 IN THE ANNEX)::
1. Unscrew the bolts (1) and remove cover (2).
2. Open the clips on the top cover of the air lter.
3. Remove the sponge lter element.
4. Remove all dirt inside the empty air lter housing.
5. Clean the lter element thoroughly in warm soapy
water.
6. Dry the sponge lter.
7. Soak a dry lter element in engine oil, then squeeze
out excess oil.
SPARK PLUGS TECHNICAL MAINTENANCE
13
Spark plug has to be intact, without soot deposits and to have a correct gap.
SPARK PLUG VERIFICATION SPARK PLUG VERIFICATION (FIG.2 IN THE ANNEX)(FIG.2 IN THE ANNEX)::
1. Unscrew the bolts and remove cover for models KSB 30i S, KSB 40iE S.
2. Remove the cap from the spark plug.
3. Remove the spark plug by means of a corresponding spanner.
4. Examine the spark plug. If is is shattered – it is necessary to replace it. For model KSB 21i S - А76RTC spark plug
or CR7HSA(NGK) equivalent is recommended, for models KSB 30i S, KSB 40iE S - BPR6ES/BP6ES(NGK), F6RTC/
F6TC(TORCH) is recommended.
5. Measure the gap. It has to be within range 0.6-0.7 mm.
6. In case of repeated use, the spark plug has to be cleaned by means of a metal brush. After that – set the correct gap.
DAMPER AND FLAME ARRESTER MAINTENANCE
14
The engine and damper will get very hot after the generator has been started. Do not touch the engine or damper
with any part of your body or clothing during inspection or repair until they have cooled down.
See Fig.1 in the Annex: Remove the screws and then pull the protective cover towards you. Loosen the bolts and
remove the cover, screen and ame arrester of the damper. Descale the screen and ame arrester of the damper with
a wire brush.Inspect the screen and ame arrester of the damper. Replace them if they are damaged. Replace the
ame arrester. Replace the screen and cover of the damper. Replace the cover and tighten the screws.
Match the protrusion of the ame arrester to the hole in the pipe
damper.
IMPORTANT!
