Kangaroo Ava 9301B - Step 2: Drawers; Prepare Drawer Components K and K1

Assembly InstructionsAva
20
K1
K
Step 2: Drawers
K1
K
6x35 Cam Bolt x4
c1
8x30 Dowel Pin x2
d1
5
⁄
8
“ Cam Cover x4
c2
Insert d1 Dowel Pins into the
edges of Panel K1.
Attach c1 Cam Bolts to Panel K.
Attach Panel K to Panel K1, inserting
cam bolts into cam locks, tightening,
and applying c2 Cam Covers.
c1
d1
