Kangaroo Hoppers - Step 2 - Trampoline Mat Assembly; Trampoline Jumping Mat; Galvanized Spring; Spring Puller

8
ASSEMBLY AND ADJUSTMENT
STEP 2
TRAMPOLINE MAT ASSEMBLY
(Two People Are Required)
7×10FT: Attach 2 springs to the round metal ring.
8×12FT: Attach 3 springs to the round metal ring.
Always install the springs in the
opposite position to make the tension
of springs averagely distribute after
one spring is attached, or you'll find
it's getting harder to attach the springs,
even unable to attach it in the end.
6
9
8
8
NO. Part Q’ty Diagram
6
Trampoline
Jumping Mat
1 pc
NO. Part Q’ty Diagram
8
Galvanized
Spring
68/84 pcs
9 Spring Puller 2 pcs
