10
ASSEMBLY AND ADJUSTMENT
STEP 4
TRAMPOLINE PAD AND NET ASSEMBLY
(Two People Are Required)
17
17
STEP 4b
STEP 4c
18
18
Hook the cloth of top net to
the plastic pole caps and 8
places in total.
Use strings to go through
the slits of the bottom net,
then go through the black
cloth loop on the jumping
mat to fix the net bottom
all around.
Lay the frame pad over the trampoline
springs so that the springs and the steel
frame are covered. Make sure that the
Frame Pad covers all metal parts.
STEP 4a
7
NO. Part Q’ty Diagram
7
Foam Pad
1 pc
18
String for
Bottom Net
1 pc
NO. Part Q’ty Diagram
17
Safety Net
1 pc
To Next Page
