Kangaroo K8805 - Page 9

Assembly InstructionsKangaroo
9
Z
D
X
c5
5
⁄
8
“ Cam Cover x4
c2
Insert c1 Cam Bolts on Panels X and Z into
cams on Panel D. Tighten cams and apply c2
Cam Covers.
NOTE: The above illustration shows panels
upside down and from the back. This is im-
portant for the next step, attaching the base
(Panel G).
Part 1: Cabinet Shell
180°
G
Z
D
c5
5
⁄
8
“ Cam Cover x8
c2
Attach Panel G to Panels
D, X and Z as shown.
Tighten cam locks and
apply c2 Cam Covers.
Make sure the casters are
locked and turn the cabi-
net over onto its wheels.
NOTE: You may need a
friend to help you, but it
is not required.
X
