Kangaroo Wallaby II - Page 22

Assembly InstructionsWallaby II
22
Step 6: Doors
Flush Hinge x3
h2
K4
K4
K4
V2a
V2b
K1
h2
s2
5
⁄
8
“ Cam Cover x11
3x14 Screw x6
c2
s2
Insert c1 Cam Bolts on Panel V2a into cams on Panel V2b. Tighten and apply Cam Covers
Insert c3 Cam Bolts on Panel V2a into cams on Panels K1 and K4. Tighten and apply Cam Covers
Attach h2 Flush Hinges to Panel V2b with s2 Screws as illustrated above
K2
K3
