Parts List: Hardware
6x35 Cam Bolt x35
3.5x14 Screw x52 3x14 Screw x28 3x20 Screw x4
Allen Wrench x1 Handle x2 Door Plate x2 14mm Wrench x1
Stay Arm x1
Cam
6x25 Cam Bolt x24
5
⁄
8
“ Cam Cover x59 6x50 Dowel Pin x33
Alignment Pin x1
Flap Hinge x3
Caster x3 Locking Plate Caster x5
Butt Hinge x2
Flush Hinge x6
Lock x1
Magnet x1
Lock plate x1
Catch plate x1Key x2
8x16 Fix Bolt x20 4x20 Fix Bolt x4
Pre-installed parts
d2
s5
b2
s2
s4
h
d3
r3
h1
h2
L
m
t1
t2
Drawer Runners
Caster Bracket
8x30 Dowel Pin x32
d1
3.5x35 Screw x4
c1
c3
h3
b1
s1
a
s
c2
c5
s3
TIP: Keep all the parts in their individually labeled bags. This will make finding parts easier as you assemble your cabinet.
Lift Rail
(Right) x1
Lift Rail
(Left) x1
Lift x1
Snag Free Hinge
h4
