Assembly InstructionsWallaby II
3
Parts List: Panels
ITEM DESCRIPTION QT Y. PACK.
A Top Panel 1 3 of 4
B
Right Leaf 1 3 of 4
C
Left Leaf 1 3 of 4
A5
Platform Cover 1 3 of 4
G
Bottom Panel 1 3 of 4
D
Back Panel 1 2 of 4
Z
Right Side Panel 1 2 of 4
A1
Quilt Extension Panel 1 2 of 4
V1
Left Door Panel 1 2 of 4
V2a
Right Main Door Panel 1 1 of 4
X
Left Side Panel 1 1 of 4
Y
Partition 1 1 of 4
F
Fixed Shelf 1 1 of 4
ITEM DESCRIPTION Q T Y. PACK.
V2b
Right Door Edge Panel 1 1 of 4
L
Drawer Front 1 1 of 4
L1
Drawer Side Left 1 1 of 4
L2
Drawer Side Right 1 1 of 4
L3
Drawer Back 1 1 of 4
L4
Drawer Bottom 1 1 of 4
O
Insert Holder 1 1 of 4
01
Gate Leg 1 1 of 4
K1
Door Bin Front Panel 1 1 of 4
K2
Door Bin Bottom Panel 1 1 of 4
K3
Door Bin Sides 2 1 of 4
K4
Fixed Shelf On Door 3 1 of 4
A4
Platform 1 1 of 4
Lift & Rails 1 4 of 4
K3
K3
K1
K2
K4
K4
K4
V2a
V2b
Z
A
C
B
A5
A1
O1
D
A4
O
G
X
V1
F
Y
L3
L1
L4
L
L2
