Kangaroo Wallaby II - Page 24

Assembly InstructionsWallaby II
24
Step 6: Doors
V1
X
s2
h2
3x14 Screw x6
s2
3.5x14 Screw x2
s1
Attach h2 Flush Hinges on Panel V1 to Panel X with s2 Screws.
You may find it helpful to have a friend help you hold the door steady as
you attach the hinges, but it is not required.
Attach s Stay Arm with s1 Screws to Panel V1
s
s1
