13
2000E 12V
PULLING CAPACITY 906 kg / 2000 lbs
MOTOR 1.0 HP (0.74kW), permanent magnets
RELAYS Brak
CONTROL SYSTEM Wired remote control
TRANSMISSION Two-stage planetary gear box
TRANSMISSION RATIO 153:1
BRAKE Dynamic
ROPE (STEEL/SYNTHETIC) 4mm x 15,2m / -
CABLE GUIDE 4-roller, steel
POWER CORDS 127cm + 174cm
DRUM DIMENSIONS 73,8 x 31,8 mm
NET WEIGHT (STEEL/SYNTHETICS) 6,25 kg / -
DIMENSIONS 285 x 100 x 106 mm
PERFORMANCE DATA
Load
kg 0 227 454 681 907
lbs 0 500 1000 1500 2000
Rope winding speed (12V)
m/min 4.1 3.28 2.6 2.2 1.12
FT/min 13.5 10.8 8.5 7.2 3.7
Operation amperage (12V) Ampere 12 33 60 85 110
Rope winding speed (24V)
m/min - - - - -
FT/min - - - - -
Operation amperage (24V) Ampere - - - - -
layer 1 2 3 4 5
Pulling capacity for respective
layers
kg 907 740 620 540 470
lbs 2000 1630 1380 1190 1050
The cumulative rope length on
the drum
m 2 4.3 7.2 10.6 14.4
ft 6.5 14 23.5 35 47
TECHNICAL PARAMETERS OF THE WINCHES
6000
PULLING CAPACITY 2722 kg / 6000 lbs
MOTOR 1.9 HP (1.4 kW), permanent magnets
RELAYS Hermetically sealed solenoid
CONTROL SYSTEM Wired – with 3.83 m cord
TRANSMISSION Three-stage planetary gear box
TRANSMISSION RATIO 226:1
BRAKE Automatic 100%
ROPE (STEEL/SYNTHETIC) 6,4mm x 16,8m / 6mm x 16m
CABLE GUIDE Four-roller / aluminium slide
POWER CORDS 173cm, 16mm2
DRUM DIMENSIONS 51,50 mm x 119mm
NET WEIGHT (STEEL/SYNTHETICS) 13.2 kg / 10.1 kg + 1 kg mounting plate
DIMENSIONS 381 x 133 x 196,5 mm
PERFORMANCE DATA
Load
kg 0 680 1361 2041 2720
lbs 0 1500 3000 4500 6000
Rope winding speed (12V)
m/min 5.8 3.4 2.65 1.8 1.2
FT/min 19.03 11.15 8.69 5.91 3.94
Operation amperage (12V) Ampere 29 93 136 188 256
Rope winding speed (24V)
m/min - - - - -
FT/min - - - - -
Operation amperage (24V) Ampere - - - - -
layer 1 2 3 4 5
Pulling capacity for respective
layers
kg 2720 2421 2013 1632 0
lbs 6000 5337 4438 3598 0
The cumulative rope length on
the drum
m 3.66 7.68 12.06 16.8 0
ft 12.01 25.2 39.7 55.12 0
12000XT-HD
PULLING CAPACITY 5443 kg/12000 lbs
MOTOR 6,5 KM, szeregowy
RELAYS Hermetyczny solenoid
CONTROL SYSTEM Na przewodzie 3,78 m, wbudowane radio
TRANSMISSION 3-stopniowa planetarna
TRANSMISSION RATIO 265:1
BRAKE Automatyczny 100%, poza bębnem
ROPE (STEEL/SYNTHETIC) 9,5mm x 26m / 10mm x 28m
CABLE GUIDE 4-rolkowa / ślizg aluminiowy
POWER CORDS 45cm+183cm, 25mm2
DRUM DIMENSIONS 63 x 254 mm
NET WEIGHT (STEEL/SYNTHETICS) 37,15kg
DIMENSIONS 535,5 x 165,50 x 244,1 mm
OSIĄGI
Load
kg 0 1361 2720 4082 5440
lbs 0 3000 6000 9000 12000
Rope winding speed (12V)
m/min 7.5 3.5 2.7 2.2 1.7
FT/min 24.6 11.48 8.86 7.22 5.58
Operation amperage (12V) Ampere 70 138 218 260 330
Rope winding speed (24V)
m/min - - - - -
FT/min - - - - -
Operation amperage (24V) Ampere - - - - -
layer 1 2 3 4 5
Pulling capacity for respective
layers
kg 5443 4332 3604 3077 -
lbs 12000 9530 7929 6770 -
The cumulative rope length on
the drum
m 5.4 11.4 19.4 28 -
ft 18 37 64 91.8 -
