12000PS
PULLING CAPACITY 5443 kg/12000 lbs
MOTOR 6,5 KM, szeregowy
RELAYS Hermetyczny solenoid
CONTROL SYSTEM Na przewodzie 3,40m i radiowe XT
TRANSMISSION 3-stopniowa planetarna
TRANSMISSION RATIO 218:1
BRAKE Automatyczny 100%, poza bębnem
ROPE (STEEL/SYNTHETIC) 9,5mm x 26m / 10mm x 28m
CABLE GUIDE 4-rolkowa / ślizg aluminiowy
POWER CORDS 175cm, 35mm2
DRUM DIMENSIONS 64 x 226 mm
NET WEIGHT (STEEL/SYNTHETICS) 35,3kg / -
DIMENSIONS 536 x 160 x 218 mm
OSIĄGI
Load
kg 0 1361 2720 4082 5440
lbs 0 3000 6000 9000 12000
Rope winding speed (12V)
m/min 6.8 4.09 2.6 1.8 1.24
FT/min 22.31 13.42 8.53 5.91 4.07
Operation amperage (12V) Ampere 75 177 270 350 419
Rope winding speed (24V)
m/min - - - - -
FT/min - - - - -
Operation amperage (24V) Ampere - - - - -
layer 1 2 3 4 5
Pulling capacity for respec-
tive layers
kg 5440 4328 3587 3063 0
lbs 12000 9522 7892 6738 0
The cumulative rope length
on the drum
m 5.4 11.2 18.8 26.8 0
ft 16.25 36.7 61.5 88 0
20000
PULLING CAPACITY 9080 KG / 20000 LBS
MOTOR 6,5KM (4,78kW), szeregowy
RELAYS Hermetyczny solenoid
CONTROL SYSTEM Na przewodzie 3,45m
TRANSMISSION 3-stopniowa planetarna
TRANSMISSION RATIO 358,4:1
BRAKE Cierny w bębnie
ROPE (STEEL/SYNTHETIC) 13mm x 22m / -
CABLE GUIDE 4-rolkowa / -
POWER CORDS 170cm, 35mm2
DRUM DIMENSIONS 88 x 221,6 mm
NET WEIGHT (STEEL/SYNTHETICS) 59,9kg / -
DIMENSIONS 560,5 x 196 x 268 mm
OSIĄGI
Load
kg 0 1810 3630 5440 9080
lbs 0 4000 8000 12000 20000
Rope winding speed (12V)
m/min - - - - -
FT/min - - - - -
Operation amperage (12V) Ampere - - - - -
Rope winding speed (24V)
m/min 6,9 3,35 2,4 1,82 1,14
FT/min 22,64 10,99 7,87 5,97 3,74
Operation amperage (24V) Ampere 33 95 168 298 470
layer 1 2 3 4 5
Pulling capacity for respec-
tive layers
kg 9080 7371 6198 5347 -
lbs 20000 16216 13636 11764 -
The cumulative rope length
on the drum
m 5,23 11,7 19,4 26 -
ft 17,15 38,4 63,7 85 -
