4
Supporting your digital lifestyle
™
−
Volume
+
OFF
Front & Rear Panels
FRONT PANEL
1 3/4” Silk Dome Tweeter
2 3” Kevlar Mid/Woofer Driver
3 LED
REAR PANEL
4 ON/OFF Switch and Volume Control
5 Right Channel Output Terminals
(+ and −) for Passive Speaker
Connection
6 3.5mm Stereo Mini-Jack AUX
7 USB Audio Input Connector
8 Subwoofer Output
9 DC Input Connection
10 Bass Reflex Port
2
3
4
6
5
7
8
9
10
1
