Kappa Juno2 - 8 Technical Data

18
8 Technical data
Max. live frame rate
30 fps, format 1920 x 1080 pixel
Full-Frame imaging
2560 x 1920 pixel, 5 megapixel
Movie Clip
1920 x 1080 pixel, 30 fps (H264 max. 8 Mbit/sec)
Sensor size
5.7 mm x 4.28 mm
Pixel size
2.2 µm x 2.2 µm
Sensor type
1/2.5“ CMOS, color
Gain
0-18 dB
Color depth
24-bit
Data format
JPEG, H264
Mechanical interface
C-mount, focal distance adjustable
Electronic Interface
Computer
LAN over RJ 45 socket, 100 Mbit over RTSP
High definition connection
1080p/30 (HDMI connector)
Remote control
IR remote control for OSD menu
LED with 2 colors
ready (green), recording (green flashing), error (red flashing)
Integrated slot
SD card (Secure Digital) 1-32GB
Buttons
white balance, still image snapshot on SD card
Additional information
Power
external power supply,
5 VDC, 4.5 W
Operating temperature
5° to +45°C
CE-conformity

Tested norms EMI/RFI

Scope of delivery
camera, power supply, cable,
remote control
