Kärcher 1350 G - Operating Controls

2
KÄRCHER 1350 G
1 Quick coupler female
2 Quick coupler male
3 Water connection with strainer
4 Detergent suction hose with filter
5 High-pressure outlet
6 High-pressure hose
7 Safety ratchet
8 Hand gun
1. Diagram of the appliance
2. Operating controls
9 Spray lance
10 Two-way nozzle
11 Air filter
12 Fuel tank
13 Engine control
14 Handle
15 Starter handle
2
1
3
4
10
9
87
6
5
11
12
13 14 15
