7
EN
Preparing the unit for use
Charging the battery
!
Ensure that the washer is switched
off via the ON / OFF button while the
battery is being charged.
Slide open the cover on the bottom of the was-
her and insert the battery so that its contacts
are aligned with those inside the washer.
Close the cover again.
Use the charger that has been supplied with
the washer to charge the battery. First of all
connect the charger to the washer and then
plug it into a mains socket.
Unplug the charger from the mains after the
battery has been on charge for approx. 15
hours.
The washer can not be operated with
the charger connected to the mains.x
Unit diagram
1 Battery
2 Switch
3 Spray head
4 Detergent tank
5 Spray pump button
6 Dirty-water tank
7 Rubber blade
8 Felt strip
9 Charger
Technical specifications
Detergent tank 125 ml
Dirty-water tank 250 ml
Weight 2.2 kg
L x B x H 280 x 105 x 215 mm
Length of suction hose 1.5 m
Unit operating cycle with full
battery approx. 20 min
Operating voltage (battery) 6 V
Charging period for fully
discharged battery approx. 15 hours
Battery charger output voltage 9 V
Charging current 500 mA
Sound level 61 dB(A)
Subject to modification
