Kärcher 397 M plus - 9 Technical Data

18
9. TECHNICAL DATA
Power Connection
Voltage ..................................................... 230-240 V -AC
Current ........................................................... 1~50 Hz
Connected/Load ............................................... 1.7 KW
Mains Fuse ........................................................ 13 AMP
Safety class ......................................................... 1
Water Connection
Supply Temperature (Max) ................................ 40 °C
Supply Rate (Min) ............................................ 600 litres per Hour
Supply Pressure (Max) ...................................... 12 bar
Supply Hose Length ......................................... 7.5 metres
Diameter ........................................................... 1/2 inch
Performance Data
Pump Pressure (Max)...................................... 110 bar
Operating Pressure ......................................... 120 bar
Flow Rate......................................................... 380 litres per hour
Detergent Intake ................................................ 20 litres per hour
Recoil Force of Hand Held Spray Gun
at Operating Pressure (Max) ............................. 10 N
Unit vibrations ................................................... 0.8 m/s²
Sound level
L
PA (EN 60704-1)............................................ 74.5 dB(A)
L
WA (2000/14/EEC) ............................................ 87 dB(A)
Optimum Working Distance on High Pressure .. 30 cm
Dimensions
Length .............................................................. 290 mm
Width ............................................................... 340 mm
Height .............................................................. 805 mm
Weight ............................................................ 12.2 Kg
Circuit Diagram
C1 Capacitor
M1 Motor
Q1 Switch
T Temperature limiter
S1 Pressure switch
