6
Assembly
see Page 19
3. GETTING STARTED
3.1 Contents
Upon opening the carton,
if you do not have all the items
as detailed please contact the
Customer Helpline.
Assembly
see Page 19
1 Transport Bracket
2 High Pressure Hose Reel
3 High Pressure Outlet
4 Power Switch (On/Off)
5 Mains Electric Lead with Plug
6 Automatic Mains Lead Rewinding
7 Support Leg
8 Inlet Water Connection (with Strainer)
9 Hosepipe Connector
10 Detergent Dosing Valve
Detergent Suction Tube with Filter
11 Detergent Tank
12 Spray Gun
13 Safety Lock Device
14 High Pressure Hose
15 Pressure Gauge
16 Four–Way Spray Lance
17 Rorary Wash Brush
Assembly
see Page 19
