REPAIR KIT
NUMBER
8.916-488.0 8.916-322.0 9.802-607.0 9.802-603.0 9.802-606.0
KIT
DESCRIPTION
Plunger
"U" Seal
20mm
4035.1
"U" Seal
Packing Assy
20mm
4035.1
Plunger
20mm
4035.1
Complete Valve
Plunger Oil
Seals
ITEM NO.S INCLUDED 4, 6, 8, 9, 10 4, 5, 6, 7, 8, 9, 10,
37, 38, 39, 40,
41, 42
14, 15, 16 3
NUMBER OF CYLINDERS
KIT WILL SERVICE
3 1 1 6 3
T.1 SERIES PUMP EXPLODED VIEW & PARTS LIST
ITEM PART NO. DESCRIPTION QTY
39* See Kit O-Ring Ø1.78 x10.82 3
40* See Kit
Teflon Ring 3
41*
See Kit Plunger 3
42* See Kit
Copper Spacer 3
43 9.803-143.0 Plunger Rod 3
44 9.803-157.0 Connecting Rod 3
45 9.802-912.0 Snap Ring 6
46 9.802-915.0 Connecting Rod Pin 3
47 9.802-889.0 Spring Washer 6
48 9.802-937.0 Connecting Rod Screw 6
49 9.803-194.0 O-Ring Ø2.62 x 152.07 1
50 9.803-166.0 Crankcase Cover 1
51 9.803-197.0 Gasket, G3/8 1
52 9.803-202.0 Sight Glass G3/4 1
53 9.802-939.0 Cover Screw 5
* Part available in kit (See below)
