EXPLODED VIEW PARTS - DUAL AXLE
ITEM PART NO. DESCRIPTION QTY
32 Pump, See Specifications Pages
33 Unloader, See Specifications Pages
34 Engine Pulley, See Specifications Pages
35 Pump Pulley, See Specifications Pages
36 Pump Bushing, See Specifications Pages
37 Engine Bushing, See Specifications Pages
38 Belts, See Specifications Pages
39 9.802-503.0 Cable, Battery, 32" Red, 4 Gauge 1
40 9.802-504.0 Cable, Battery, 36" Black, 4 Gauge 1
41 9.802-177.0 Valve, Shut-Off, 1/4 Turn 1
42 9.802-710.0 Bolt, 5/16" x 1", NC HH 4
43 9.802-727.0 Bolt, 3/8" x 1-3/4" (Diesel Models Only) 4
9.802-728.0 Bolt, 3/8" x 2", NC, HH (5000 PSI Models Only) 4
44 9.802-054.0 Elbow, Fuel Tank, Zinc (Diesel Models Only) 1
45 9.802-728.0 Bolt, 3/8" x 2" NC, HH 2
46 9.803-845.0 Bolt, 1/2" x 5" NC HH Tap (5000 PSI Models Only) 1
9.802-740.0 Bolt, 1/2" x 3-1/2", NC, HH (Diesel Models Only) 1
47 9.802-751.0 Screw, 1/4" x 5/8", Phil PH MS 4
48 9.802-782.0 Collar, 5/8" Bore Shaft 8
49 9.802-820.0 Washer, Nylon Spacer, 0.656 x 1.25 x 0.65 4
50 9.802-870.0 Block, Unloader, 3/8" x 3/8" Brass 1
51 9.803-037.0 Axle, 5/8" x 31.25" 2
52 9.803-104.0 Guard, Belt, Rear Steel 1
53 8.912-480.0 Assembly, Weld, Battery Brkt, CW Cage, Black 1
9.803-847.0 Assembly, Weld, Battery Brkt, CW Cage, Red 1
8.912-502.0 Holder, Nozzle 1
54 9.802-964.0 Assembly, Weld, Cage, CW Black 1
8.912-486.0 Assembly, Weld, Slider, CW Cage, Red 1
55 9.803-304.0 Guard, Belt, Front, CW Cage, Large 1
56 9.802-967.0 Assembly, Weld, Slider, CW Cage, Black 1
8.912-497.0 Assy, Weld, Slider, CW Cage, Red 1
9.803-846.0 Slider, Assembly, Black (Diesel Models Only) 1
57 9.802-765.0 Screw, 1/4" x 1/2" BH SOC CS 7
58 9.802-773.0 Nut, 1/4" ESNA, NC 4
59 9.802-804.0 Washer, 5/16" Flat, SAE 20
60 9.802-776.0 Nut, 5/16" ESNA, NC 12
61 9.802-708.0 Screw, 5/16"-18 x 3/4" M PH TRH 4
62 9.802-124.0 Plug, 1/4" Countersunk (5000 PSI Models Only) 1
63 9.802-744.0 Bolt, 10mm x 20mm, HH 4
64 9.802-070.0 Grip, 1" Square Handle 2
65 9.802-118.0 Tee, 1/2", Branch Male 1
66 9.802-996.0 Bracket, Brake Pad, Black 1
8.912-019.0 Bracket, Brake Pad, Red 1
67 9.802-997.0 Linkage, Brake, Black 1
8.912-020.0 Linkage, Brake, Red 1
68 9.802-809.0 Washer, 1/2" Flat 1
69 9.802-966.0 Handle, Break, CW Cage, Black 1
8.912-495.0 Handle, Brake, CW Cage, Red 1
