9.800-414.0 • Rev. 11/09
PRESSURE WASHER
OPERATOR’S MANUAL
9
ITEM PART NO. DESCRIPTION QTY
70 9.802-705.0 Bolt, Carriage, Zinc, 1/4"-20 x 1.0 PLT 4
71 9.802-210.0 Clamp, Hose, .46-.54 ST (Honda and Diesel Models) 2
72 9.802-802.0 Washer, 1/4" Flat, SAE 12
73 9.802-803.0 Washer, 1/4" Flat, SAE, Black, Zinc 5
74 9.802-810.0 Washer, 5/8" Flat 8
75 9.803-843.0 Valve, Safety Relief, 6000PSI (5000 PSI Models Only) 1
76 9.802-030.0 Elbow, 3/8" Street, Female (5000 PSI Models Only) 1
77 8.705-974.0 Nipple, 3/8" Hex Steel (5000 PSI Models Only) 1
78 9.802-039.0 Elbow, 1/2" JIC, 3/8", 90° 1
79 9.802-689.0 Muffler, Honda,GX620/670 Right (5000 PSI Models Only) 1
8.915-687.0 ▲ Deflector, Exhaust, Honda 1
9.803-631.0 ▲ Muffler, Exhaust, Vanguard 16 HP 1
9.803-867.0 ▲ Guard, Muffler, Vanguard, 16 HP 1
9.802-868.0 ▲ Brace, Muffler Guard, 16 HP 1
8.718-028.0 ▲ Muffler, Deflector, Vanguard 1
80 9.800-034.0 Clear Lexan 1
81 9.800-014.0 Label, Intended For Outdoor Use 1
82 9.802-254.0 Hose, 1/4 Push-On (Diesel Models) 7.66 ft.
83 9.802-035.0 Plug, 1/8" Square Head, Black 1
84 9.802-148.0 Adaptor, 1/2" x 1/2" 1
85 9.802-770.0 Screw, 1/4" x 1" (5000 PSI Models) 2
86 9.802-803.0 Washer, 1/4" Flat, SAE, Black (5000 PSI Models) 2
87 9.802-773.0 Nut, 1/4" ESNA (5000 PSI Models) 2
88 9-802-807.0 Washer, 3/8" Flat 10
89 9.197-003.0 Nut, 3/8" ESNA 6
90 9.803-305.0 Bracket, Regulator 1
91 9.800-049.0 Label, Manufacturer's Cleaning Solution 1
92 9.802-816.0 Washer, 7/16" Lock, Split Ring 4
93 9.802-225.0 Chemical Injector Assy., 3-5 GPM, .83 (Diesel & Vanguard Models) 1
9.802-226.0 Downstream Inj. Assy, 5000 PSI (5000 PSI Models Only) 1
94 9.802-259.0 Hose, 1/2" Push-On 14"
95 9.802-126.0 Plug, 1/2" JIC 1
96 9.802-129.0 Elbow, 1/2" JIC x 3/8" 1
97 9.802-203.0 Clamp, 1/2" 1
98 9.802-771.0 Screw, 10/32" 1
99 9.804-567.0 Nut, 10/32" 1
100 9.802-802.0 Washer, 1/4" Flat, SAE 1
101 8.916-084.0 Label, C-Tech EPA 1
102 9.802-741.0 Bolt 8mm x 16mm (5000 PSI Models) 4
103 9.802-813.0 Split Washer 5/16 (5000 PSI Models) 103
104 9.803-838.0 Connector Battery Post 2
105 8.704-660.0 Label, Shark, Die-cut (HD and BR Only) 1
106 8.917-015.0 Label, Regulation 4442.6 1
▲ Not Shown
EXPLODED VIEW PARTS - DUAL AXLE
