Kärcher BD 43/25 C Classic Bp Pack 80 Ah Li User Manual

- 7
We hereby declare that the machine de-
scribed below complies with the relevant
basic safety and health requirements of the
EU Directives, both in its basic design and
construction as well as in the version put
into circulation by us. This declaration shall
cease to be valid if the machine is modified
without our prior approval.
The signatories act on behalf of and with of
the authority of the company management.
Documentation supervisor:
S. Reiser
Alfred Kärcher SE & Co. KG
Alfred-Kärcher-Straße 28-40
71364 Winnenden (Germany)
Tel.: +49 7195 14-0
Fax: +49 7195 14-2212
Winnenden, 2021/02/01
We hereby declare that the product de-
scribed below complies with the relevant
provisions of the following UK Regulations,
both in its basic design and construction as
well as in the version put into circulation by
us. This declaration shall cease to be valid
if the product is modified without our prior
approval.
The signatories act on behalf of and with of
the authority of the company management.
Documentation supervisor:
S. Reiser
Alfred Kärcher SE & Co. KG
Alfred-Kärcher-Straße 28-40
71364 Winnenden (Germany)
Tel.: +49 7195 14-0
Fax: +49 7195 14-2212
Winnenden, 2021/02/01
Only use original accessories and spare
parts, they ensure the safe and trouble-free
operation of the device.
For information about accessories and
spare parts, please visit www.kaerch-
er.com.
Pad, green (medium hard) 6.369-472.0 For cleaning heavily soiled floors and for deep cleaning.
Pad, white 6.369-469.0 For polishing floors.
Pad, black (hard) 6.369-473.0 With stubborn soiling and for deep cleaning.
Microfiber pad 6.905-526.0 Routine cleaning and basic cleaning of fine stoneware tiles
Pad, beige (natural hair proportion) 6.371-081.0 For polishing and refreshing of hard and flexible floorings.
Diamond pad, white 6.371-256.0 For coarse cleaning and upvaluation. Removes small scratches and ensures a
clean, semi-gloss surface.
Diamond pad, yellow 6.371-257.0 For coarse cleaning and upvaluation. Removes fine scratches and ensures an
even more homogenous and shiny surface.
Diamond pad, green 6.371-238.0 For polishing high-gloss coated floor coverings and for quick polishing of terraz-
zo and natural stone surfaces.
Suction bar, 850 mm, straight 4.777-401.0
Suction bar, 850 mm, bent 4.777-411.0
Set homebase box 4.035-406.0
Mop holder 9.753-023.0
Adapter Homebase 5.035-488.0
Double hook 6.980-077.0
Mop clip 6.980-078.0
Bottle hook 6.980-080.0
Universal hook 4.070-075.0
Technical specifications
Power
Nominal voltage V 24
Battery capacity Ah
(5h)
80
Average power consump-
tion
W 1100
Rated power suction tur-
bine
W500
Rated power brush drive W 600
Vacuuming
Vacuum power, air vol-
ume (max.)
l/s 24
Vacuuming power, nega-
tive pressure (max.)
kPa
(mbar)
12 (120)
Type of protection IPX 3
Cleaning brushes
Brush speed 1/min 155
Brush diameter mm 430
Dimensions and weights
Theoretical surface
cleaning performance
m²/h 1600
Max. working range in-
cline
%2
Fresh/waste water tank
volume
l 25/25
Max. water temperature °C 50
Ambient temperature °C 5...40
Net weight (transport
weight)
kg 76
Total weight (ready to op-
erate)
kg 102
Dimensions of battery
compartment
mm 350 x
350
Values determined as per EN 60335-2-
72
Total oscillation value m/s
2
<2,5
Uncertainty K m/s
2
0,2
Sound pressure level L
pA
dB(A) 66
Uncertainty K
pA
dB(A) 1
Sound power level L
WA
+
Uncertainty K
WA
dB(A) 81
EU Declaration of Conformity
Product: Floor cleaner
Type: 1.127-xxx
1.515-xxx
Relevant EU Directives
2006/42/EC (+2009/127/EC)
2014/30/EU
2011/65/EU
Applied harmonized standards
EN 60335–1
EN 60335–2–72
EN 55012: 2007 + A1: 2009
EN 61000–6–2: 2005
EN 62233: 2008
EN IEC 63000: 2018
Applied national standards
-
Declaration of Conformity
Chairman of the Board of Management
Director Regulatory Affairs & Certification
Product: Floor cleaner
Type: 1.127-xxx
1.515-xxx
Currently applicable UK Regulations
S.I. 2008/1597 (as amended)
S.I. 2016/1091 (as amended)
S.I. 2012/3032 (as amended)
Designated standards used
EN 60335–1
EN 60335–2–72
EN 55012: 2007 + A1: 2009
EN 61000–6–2: 2005
EN 62233: 2008
EN IEC 63000: 2018
National standards used
-
Accessories and Spare Parts
Chairman of the Board of Management
Director Regulatory Affairs & Certification
17EN

Kärcher BD 43/25 C Classic Bp Pack 80 Ah Li Specifications

General

Working Width	430 mm
Fresh Water Tank Capacity	25 l
Dirty Water Tank Capacity	25 l
Battery Voltage	36 V
Battery Capacity	80 Ah
Brush Speed	180 rpm
Working Width, Vacuum	850 mm
Battery Type	Lithium-ion
Area Performance Theoretical	1720 m²/h
Battery Running Time	4 h
Brush Contact Pressure	30 g/cm²
