20 English
Description of the device
The maximum amount of equipment is described in
these operating instructions. Depending on the model
used, there are differences in the scope of delivery (see
packaging).
For the illustrations, refer to the graphics page.
Illustration A
1 ON/OFF switch
2 Boost function button
Increased roller speed and additional water quantity
for stubborn dirt
3 Button for adjusting the cleaning level
Switching between cleaning level 1 and 2
4 "Cleaning level 2" indicator
Increased roller speed and amount of water
5 "Cleaning level 1" indicator
Normal roller speed and amount of water
6 "MAX" indicator (red)
The waste water tank is full
7 "MIN" indicator (blue)
The fresh water tank is empty
8 "Battery" indicator (green)
Indicates the charging state of the battery
9 Wall anti-slip handle
10 Handle
11 Fresh water tank
12 Removable hair filters
13 Unlocking button for the waste water tank and park-
ing station
14 Cleaning rollers (4 x)
15 Waste water tank
16 * LED lighting
17 Unlocking button for hair filters
18 Charging socket
19 Parking station
20 Cleaning station with cleaning brush
21 Charger with charging cable
22 * Cleaning rollers for stone floors (4 x)
23 Detergent RM 536 (30 ml)
24 * Detergent RM 537 (30 ml)
25 * Detergent RM 536 (500 ml)
* FC 7 Premium
Installation
Installing the handle bar
1. Hold the basic device firmly.
2. Place the cable in the guide of the plastic connector
and fix it.
3. Fit the handle bar all the way to the end stop into the
basic device until it audibly latches into place. The
handle bar must sit tightly in the device.
Illustration B
Initial startup
Charging process
1. Plug the charging cable of the charger into the
charging socket on the device.
Illustration C
2. Plug the mains plug of the charger into the socket.
The LED indicator lights display the battery's current
charging state.
Illustration D
All 3 LED indicator lights flash from bottom to top
when charging a completely empty battery.
The lowermost LED lights up continuously when the
battery is 1/3 charged, the two upper LEDs continue
to fl
ash.
Wh
en the battery is 2/3 charged, the two lower
LEDs light up continuously, the uppermost LED con-
tinues to flash.
The battery is fully charged after 4 hours.
After the battery has been charged, the 3 LED indi-
cator lights remain on constantly for 60 minutes. Af-
ter this time, the LED indicator lights go out.
3. Unplug the charger mains plug from the mains sock-
et after charging.
Illustration E
4. Unplug the charging cable from the device.
Fitting the waste water tank
1. Place the device in the middle of the waste water
tank so that it is positioned between the rollers and
then audibly clicks into place. The position of the
tank is not important because it can be inserted in
both longitudinal directions in the device.
Illustration F
The waste water tank must sit tightly in the device.
Filling the fresh water tank
1. Grasp the fresh water tank by the recessed grips at
the side and remove it from the device.
2. Open the tank cap and turn it to the side.
Illustration G
3. Fill the fresh water tank with cold or lukewarm tap
water.
4. Add KÄRCHER detergent or care agent to the fresh
water tank as required.
ATTENTION
Overdosing or underdosing of the detergent or care
agent
Can result in poor cleaning results.
Follow the dosage recommendations for the detergent
or care agent.
5. Close the tank cap.
6. Fit the fresh water tank into the device.
Illustration H
The fresh water tank must sit tightly in the device.
Operation
General notes on operation
ATTENTION
Moisture
Material damage to sensitive floors
Check the surface to be cleaned for water sensitivity at
an inconspicuous location before using the device.
Do not clean water-sensitive floor coverings such as
e.g. untreated cork floors, since the moisture can pene-
trate and damage the floor.
