22
The device switches on
As soon as the waste water tank has exceeded a vol-
ume of 200 ml, automatic device shutdown is activated.
If detergents from other manufacturers are used, exces-
sive foaming can occur and the device shutdown is ac-
tivated before the 200 ml level is reached.
Empty the waste water tank.
Use only KÄRCHER detergent and be sure to use
the correct dosage.
The device engages in joints when used
The knobs on the underside of the waste water tank are
damaged or worn.
Contact the authorised Customer Service.
Removing the handle
ATTENTION
Frequent removal of the handle
The handle components can be damaged by repeated
removal.
Do not remove the handle from the basic device after
assembly.
The handle may only be removed from the basic device
when the device is sent out for service purposes.
ATTENTION
Incorrect removal of the handle
Device damage
Take care to ensure that the connection cable between
the basic unit and the handle is not damaged.
Insert a screwdriver at a 90° angle in the small open-
ing at the rear side of the handle and remove the
handle.
Illustration AK
Technical data
Subject to technical modifications.
FC 7
Electrical connection
Voltag
e V
1
00
-
240
Phase ~ 1
Frequency Hz 50 - 60
Degree of protection IPX4
Device protection class III
Charger protection class II
Nominal power of device W 80
Nominal voltage of battery V 25.20 -
25.55
Battery type Li-Ion
Operating time when battery is ful-
ly charged
min 45
Charging time for an empty bat-
tery
h4
Output voltage of charger V 30
Output current of charger A 0.6
Device performance data
Roller rotations per minute at
cleaning level 1
rpm 450
Roller rotations per minute at
cleaning level 2
rpm 490
Roller rotations per minute with
Boost function
rpm 530
Filling quantity
Fresh water tank capacity ml 400
Waste water tank capacity ml 200
Dimensions and weights
Weight (without accessories and
cleaning fluids)
kg 4.3
Length mm 310
Width mm 230
Height mm 1210
FC 7
