36 English
Specifications
Type HDS 551 C Eco
Main Supply
Voltage V 230 240 240 220
Kind of current Hz 1~ 50 1~ 50 1~ 50 1~ 60
Connection output kW 3,2 3,2 3,0 3,2
Protection (slow) A 16 15 13 16
Maximum allowed net impedance Ohm (0.328+j 0.205)
Water connection
Max. feed temperature °C 30
Min. feed volume l/h (l/min) 700 (11,7)
Suck height from open container
(20 °C)
m0,5
Performance data
Water flow rate l/h (l/min) 550 (9,2) 530 (8,8) 530 (8,8) 530 (8,8)
Working pressure water (nozzle
included)
MPa (bar) 13 (130) 13 (130) 12 (120) 13 (130)
Steam flow rate l/h (l/min) --
Working pressure steam operation
max. (with steam nozzle 4.766-023)
MPa (bar) --
Operating temperature hot water
max.
°C 90
Working temperature steam opera-
tion
°C --
Detergent suck in l/h (l/min) 0-20 (0-0,3)
Burner performance kW 47
Recoil force of handgun max. N 24
Noise emission
Sound pressure level (EN 60704-1) dB(A) 77
Guaranteed sound power level
(2000/14/EC)
dB(A) 93
Machine vibrations Vibration total value (ISO 5349)
Hand spraygun m/s² 2,6
Ray tube m/s² 2,3
Fuel
Fuel Fuel oil EL or Diesel
Amount of oil l 0,5
Oil grade Engine oil 15 W 40 (6.288-050)
Dimensions and weights
Length x width x height mm 940 x 600 x 740
Weight without accessories kg 80
Fuel tank l 16
Detergent Tank l 8
