Subject to technical modifications!
We hereby declare that the machine de-
scribed below complies with the relevant ba-
sic safety and health requirements of the EU
Directives, both in its basic design and con-
struction as well as in the version put into cir-
culation by us. This declaration shall cease to
be valid if the machine is modified without our
prior approval.
The undersigned act on behalf and under the
power of attorney of the company manage-
ment.
Alfred Kärcher GmbH Co. KG
Alfred-Kärcher-Str. 28 - 40
71364 Winnenden (Germany)
Phone: +49 7195 14-0
Fax: +49 7195 14-2212
Technical specifications
K 3.600
K 4.600
K 5.600
Water connection
Max. feed temperature °C 40
Min. feed volume I/min 10
Max. feed pressure MPa 0.8
Max. Suction height m 0.5
Electrical connection
Voltage *GB
1~50 Hz
V 230 240
Connected load kW 1.8 1.9 2.1
Mains fuse *GB
(slow-blow)
A 13
Protective class I
Protection class IP X5
Performance data
Working pressure MPa 11 12 12,5
Max. permissible pres-
sure
MPa 12 13 14
Water flow rate I/min 6.3 6.7 7.5
Dimensions and weights
Length mm 876
Width mm 325
Height mm 285
Weight, ready to oper-
ate with accessories
kg 12.9 13.2 13.9
Detergent flow rate I/min 0 - 0.3
Recoil force of trigger
gun
N 15
Values determined as per EN 60335-2-79
Hand-arm vibration
value
Uncertainty K
m/s
2
m/s
2
< 2,5
0.3
Sound pressure level
L
pA
Uncertainty K
pA
dB(A)
dB(A)
73
2
75
2
71
2
Sound pressure level
L
WA
+ Uncertainty K
WA
dB(A) 89 91 86
CE Declaration
Product: High-pressure cleaner
Type: 1.180-xxx 1.181-xxx
Relevant EU Directives
98/37/EC (to 28.12.2009)
2006/42/EC (from 29.12.2009)
2004/108/EC
2000/14/EC
Applied harmonized standards
EN 55014–1: 2006
EN 55014–2: 1997 + A1: 2001
EN 60335–1
EN 60335–2–79
EN 61000–3–2: 2006
EN 61000–3–3: 2008
EN 62233: 2008
Applied conformity evaluation method
Appendix V
Sound power level dB(A)
K 3.600 K 4.600 K 5.600
Measured: 87 88 84
Guaranteed: 89 91 86
CEO
Head of Approbation
% "#
