English 19
Illustrations on fold-out page!
1 Garden hose connector
(female)
2 Coupling element for water connection
3 Water connection with integrated sieve
4 Quick coupling for high pressure hose
5 Appliance switch „0/OFF“ / „I/ON“
6 Transport handle, detachable
7 Accessory net
8 Mains cable with mains plug
9 Detergent suction hose with filter
10 Transport wheel with wheel cap
11 Trigger gun
12 Lock trigger gun
13 Key to detach the high pressure hose
from the trigger gun
14 High pressure hose
15 Spray lance with Dirtblaster
For strong contaminations
16 Spray lance with pressure regulation
(Vario Power)
Carrying out the most common cleaning
tasks. The work pressure can be stage-
lessly regulated between "Min" and
"Max". You can add detergent when
"Mix" is selected.
In order to adjust the working pressure,
release the lever of the trigger gun and
turn the spray lance to the desired posi-
tion.
Not included in the delivery
17 Water supply hose
Special accessories expand the possibili-
ties of using your appliance. Please contact
your KÄRCHER dealer for further informa-
tion.
Illustrations on fold-out page!
Mount loose parts delivered with
appliance prior to start-up.
Illustration
Push the wheels into the intake and se-
cure them with the plugs. Align the plug
properly.
Illustration
Place the transport handle into the in-
take until you feel resistance. Use the
heel of your hand or a soft rubber mallet
to position it.
Illustration
Hook the accessories net into the hooks
shown in the illustration.
Description of the Appliance
Special accessories
Assembly
Install wheels
Install the transport handle
Attach the accessories net
