English 11
pose a potential danger to human health and the envi-
ronment. However, these components are required for
the correct operation of the appliance. Appliances
marked by this symbol are not allowed to be disposed
of together with the household rubbish.
Cleaning work producing in oily waste water, e.g.
washing engines, washing undercarriages etc.,
may only be performed at washing stations with an oil
separator.
Working with detergents may only be performed on
watertight surfaces with connection to the waste
water sewage system. Do not allow detergent to enter
waterways or the soil.
Extraction of water from public waterways is not
permitted in some countries.
Notes on the content materials (REACH)
Current information on content materials can be found
at: www.kaercher.de/REACH
Intended use
Use the high-pressure cleaner in private households
only.
The high-pressure cleaner is intended for cleaning ma-
chines, vehicles, buildings, tools, façades, terraces,
garden machines etc. using a high-pressure water jet.
Accessories and spare parts
Only use original accessories and original spare parts.
They ensure that the appliance will run fault-free and
safely.
Information on accessories and spare parts can be
found at www.kaercher.com.
Scope of delivery
The scope of delivery for the appliance is shown on the
packaging. Check the contents for completeness when
unpacking. If any accessories are missing or in the
event of any shipping damage, please notify your deal-
er.
Description of the device
The maximum amount of equipment is described in
these operating instructions. Depending on the model
used, there are differences in the scope of delivery (see
packaging).
For the illustrations, refer to the graphics page
Illustration A
1 Stand with carrying handle
2 Water connection with integrated sieve
3 Transport wheel
4 Visor
5 Hose guide
6 Trigger "0/OFF" / "I/ON"
7 Storage for spray lance
8 High-pressure hose
9 *Plug 'n' Clean detergent bottle
10 Storage / parking position for high-pressure gun
11 Transport handle, telescoping
12 Power Control spray lance dirt grinder for stubborn
dirt, pressure level: HARD
13 Vario Power Power Control spray lance for the most
common cleaning tasks, pressure levels: HARD /
MEDIUM / SOFT / MIX
14 Power Control high-pressure gun
15 Button for separating the high-pressure hose from
the high-pressure gun
16 High-pressure gun lever
17 Pressure indicator (0-MIX / 1-SOFT / 2-MEDIUM /
3-HARD)
18 High-pressure gun lock
19 Carrying handle
20 Hose holder
21 Type plate
22 Accessory compartment
23 Hook for net attachment
24 Accessory compartment net
25 Mains connection with mains plug
26 Water connection coupling
27 **Garden hose with commonly available coupling
– Fabric reinforced
– Diameter of at least 1/2 inch (13 mm)
– Length at least 7.5 m
28 **KÄRCHER suction hose for water supply from
open containers (order no. 2.643-100.0)
29 Supplied screws and dowels
30 *Foam nozzle with detergent container
The detergent is sucked out of the container to pro-
duce a strong detergent foam.
31 *Rotating washing brush (e.g. for washing cars)
* optional, ** additionally required
Supplied screws and dowels
Illustration B
1 Stand dowels (2 pieces)
2 Screw M 4x20 (2 pieces)
3 Screw M 4x22 (2 pieces)
4 Screw M 4x16 (8 pieces)
Safety devices
몇 CAUTION
Missing or modified safety devices
Safety devices are provided for your own protection.
Never modify or bypass safety devices.
Power switch
The power switch prevents unintentional operation of
the device.
High-pressure gun lock
The lock locks the lever of the high-pressure gun and
prevents the device from starting unintentionally.
Auto-stop function
If the lever of the high-pressure gun is released, the
pressure switch turns off the pump and the high-pres-
sure jet stops. The pump switches on again when the le-
ver is pressed.
Motor circuit breaker
The motor circuit breaker shuts off the device if power
consumption it too high.
