6
1 Commutateur (MARCHE/ARRET)
2 Prise d’eau à crible
3 Raccord
4 Raccord
5 Poignée-pistolet à cran d’arrêt (A)
6 Tuyau haute pression
7 Lance à régulation de pression
8 Lance à rotabuse
9 Etrier de transport
10Support d´enroulage du flexible haute pression
11Câble de branchement
12Poignée de transport
13Flexible d´aspiration de détergent à bague de dosage
14Sortie haute pression
1 Appliance switch (ON/OFF)
2 Water connection with filter
3 Quick coupler male
4 Quick coupler female
5 Spray gun with safety ratchet (A)
6 High-pressure hose
7 Spray wand with pressure regulator
8 Spray wand with dirt blaster
9 Transport bracket
10Holder for high-pressure hose
11Connection lead
12Carrying handle
13Detergent suction hose with dosing ring
14High-pressure outlet
OVERVIEW – Model K 502 MS plus
GÉNÉRALITÉS – Modéle K 502 MS plus
