Kärcher NT 27/1 Service Manual

English 5.906-472.0 Rev. 00 (08/08) 7
After a certain amount of use, the cartridge filter is dirty and must
be cleaned or replaced as needed.
Î Remove the suction head (see chapter 4.2).
Î Unscrew the fastening nut (1).
Î Remove the cartridge filter (2) toward the top.
Î Install the cleaned or new cartridge filter in reverse order.
The seal (arrow) in the suction head can be replaced as follows if
needed.
Î Remove the suction head (see chapter 4.2).
Î Remove the seal from the suction head and insert new seal.
Remove the swimmer as follows to clean it.
Î Remove the cartridge filter (see chapter 5.1).
Î Remove the fastening screws (3).
Î Remove the swimmer casing (1).
Î Remove the swimmer (2) from the swimmer casing. The swim-
mer can now be cleaned or replaced if necessary.
Note
When installing the swimmer (2) make sure that the open side of
the swimmer is located inside the swimmer casing. If the swimmer
(2) is inserted the wrong way, it will lose its efficiency. This can
cause damages to the appliance.
1 Swimmer casing
2Float
3 Fastening screws (2x), swimmer casing
5 Basic settings and service procedures
5.1 Remove cartridge filter
5.2 Replace seal
5.3 Remove the swimmer

Kärcher NT 27/1 Specifications

General

AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Maximum input power	1380 W
Annual energy consumption	- kWh
Type	Drum vacuum
Hose length	2.5 m
Cleaning type	Dry&wet
Dust capacity	27 L
Flexible hose	Yes
Product color	Black, Grey, Yellow
Tube material	Metal
Container material	Plastic
Dust container type	Bagless
Airflow	67 l/s
Proper use	Professional
Noise level	72 dB
Cable length	7.5 m
Vacuum air filtering	-
Handles quantity	1
Standard nominal width	35 mm

Weight and Dimensions

Width	420 mm
Height	525 mm
Weight	7500 g
