Kärcher NT 48/1 Original Instructions

10 English
Technical data
Subject to technical modifications.
NT 48/1
Electrical connection
Mains voltage V 120
Phase ~ 1
Power frequency Hz 60
Degree of protection IPX4
Protection class II
Rated current A 10
Device performance data
Tank content gal (l) 12.7 (48)
Fluid filling quantity gal (l) 9.2 (35)
Air quantity (max.) CFM 
(l/s)
87 (41)
Vacuum (max.) mm
(kPa)
2366 (23.2)
Air quantity (max., suction motor) CFM 
(l/s)
150 (71)
Vacuum (max., suction motor) mm
(kPa)
2498 (24.5)
Dimensions and weights
Typical operating weight lbs (kg) 22.5 (10.2)
Length x width x height in (mm) 19.3 x 15.4 x 30.7 (490 x 390 x
780)
Diameter of the suction hose in (mm) 1.38 (35)
Ambient conditions
Ambient temperature (max.) °F (°C) 104 (+40)
Determined values in acc. with EN 60335-2-69
Sound pressure level L
pA
dB(A) 72
Uncertainty K
pA
dB(A) 1
Mains cable
Power cord type SJTW-A 2/16 AWG
Part number (CUL) 6.648-370.0
Cable length ft (m) 25 (7.5)

Kärcher NT 48/1 Specifications

General

Standard nominal width	35 mm
Dust capacity	48 L
Container material	Plastic
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Maximum input power	1380 W
Airflow	67 l/s
Noise level	72 dB

Weight and Dimensions

Depth	390 mm
Width	490 mm
Height	780 mm
Weight	10500 g
