Kärcher OC 3 Operator's Manual

English 9
4. Remove the fine filter using the suc-
tion hose connection or suitable pliers.
5. Remove the fine filter from the suc-
tion hose connection.
6. Insert the suction hose connection
into the device and fix it in
place by
turning it 90°.
7. Hang the suction hose with integrat-
ed filter in the source of water (e.g.
in a water bucket).
ATTENTION
Loss of valve opener and fine filter
Operation of the device not possible
Keep the valve opener and the fine fil-
ter in the storage compartment.
Insert the valve opener and the fine fil-
ter before using the water reservoir.
Make sure that the pin of the valve
opener points upwards.
Operation
ATTENTION
Dry running of pump
Damage to the device
If the device does not build up any
pressure within 2 minutes, then switch
off the device and proceed according
to the instructions in chapter Trouble-
shooting guide.
1. Press the power switch.
2. Press the lever of the trigger gun.
Approx. 2 minutes before the en
d of
the operating time (see chapter Tech-
nical data), the charge level indicator
starts to flash.
a
b

Kärcher OC 3 Specifications

General

Form factor	Compact
Hose length	2.8 m
Power source	Battery
Water filter	Yes
Cleaning type	Dry
Product color	Black, Yellow
Tank capacity	4 L
Detergent tank	-
Pressure range	Low-pressure
Protection class	III
International Protection (IP) code	IPX4
Battery life	15 min
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Battery recharge time	3 h
Uncertainty K	3 dB
Maximum flow rate	120 l/h
Sound power level	84 dB
Sound pressure level	69 dB
Working pressure (max)	- bar
Maximum water temperature	40 °C
Wash brush	No
Package weight	2900 g

Weight and Dimensions

Depth	277 mm
Width	234 mm
Height	201 mm
Weight	2200 g
