Kärcher PUZZI 64/35E - Controls

10 86343360 PUZZI 64/35E
Operations
Controls
1. Vacuum Accessory Tool Hook-up
2. Solution Pump Switch
3. Vacuum 1 Switch
4. Vacuum 2 Switch
5. Heater Switch with On Light (Units w/Heat Only)
6. Pressure Gauge
1
2
3
4
5
6
7
8
9
10
11
7. Adjustable Pressure Relief Valve
8. Heater Temperature Light (Units w/Heat Only)
9. Breaker for Vacuum 2
10. Breaker for Vacuum 1
11. Solution Accessory Tool Hook-up
