Kärcher PUZZI 64/35E - Page 21

86343360 PUZZI 64/35E 21
Control Panel
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86180350 12-800035 1 ELL, 1/4FP X 1/4T BR
2 86202230 390-09A 2 WASHER 9/16 S/S USS THICK
3 86002370 20035 1 CLAMP, 7/16 DIA NYLON UL
4 86002450 22015 1 COUPLER, 1/4 QD
5 86197390 31021 1 ELBOW, 1/4NPT 45D STREET
6 86005700 57104 2 NUT, 10-32 HEX W/STAR
7 86276820 70740 6 SCR, 10-32 X 1/2 PTHMS BLK NP
8 86007140 72130 3 SWITCH, SPST 2-POSITION ROCKER
9 86008900 80845 2 BOOT, SEAL PUSH BUTTON 7/16”
10 86311840 - 1 PANEL, CONTROL, 500 HEAT
11 86313020 - 2 GASKET, .125 T X .25 W X 15.6”
12 86313030 - 4 GASKET, .125 T X .25 W X 7.2”
13 86318320 - 2 BREAKER, 13A, 250VAC, 32VDC
14 86323310 - 1 GAUGE, 0-600 PSI
15 86318780 - 1 LIGHT ASM, HEATER, 120V
16 86317850 - 1 SWITCH, LIGHTED 2-POS ROCKER
17 86233480 - 1 CLIP, NEON LAMP
18 86005720 57106 2 NUT, 8-32 STAR
