Kärcher PUZZI 64/35E - Page 31

86343360 PUZZI 64/35E 31
Pump
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86190520 11-800224 2 PLUG, 3/8 SOCHD BR
2 86317840 - 1 HOSE,PULSE 16” 1/4MPT X 1/4MPT
3 86323300 - 12 WASHER, 1/4” RUBBER
4 86197270 04008 1 ADPTR, 1/4MPT X 1/4FPT BR
5 86197290 14076 1 BUSHING, 3/8 MPT X 1/4 FPT HEX
6 86233150 20042 2 CLAMP, 3/8 WORM GEAR
7 86197360 31016 2 ELBOW, 1/4 NPT STREET
8 86197420 31026 1 ELBOW, 3/8NPT STREET
9 86282320 39710 1 HOSE, 1/2ID WIRE BOUND X 26”
10 86240500 40095 1 HOSEBARB, 3/8MPT X 3/8HOSE 90
11 86005810 57245 4 NUT, 1/4-20 HEX NYLOCK SS
12 86273810 70018 4 SCR, 1/4-20 X 1.00 HHCS SS
13 86197760 78308 1 TEE, 1/4 STREET
14 86321660 - 1 ELBOW, 1/4 MPT X 1/8 FPT
15 86010630 87013 8 WASHER, 1/4 X 5/8 FLAT SS
16 86317550 - 1 HOSEBARB, 3/8 MPT X 1/2 90 BR
17 86318980 - 1 MOTOR, M53, 120V, 3A W/ CAM
INCLUDES
RECTIFIER
18 86318990 - 1 PUMP, SERIES 207V
19 86321290 - 1 BPR, 500PSI
20 86321470 - 1 HOSE, 3/8ID WIRE BOUND X 26"
21 86317590 - 1 HOSE, 10” 1/4JIC X 1/8MPT SS
22 86270850 57026 3 NUT, 8-32 HEX NYLOCK
23 86323550 - 1 HOSE, 47" HP 1/4-MPT X 1/4-MPT
24 86321280 - 1 BRKT, D/P BPR
