Kärcher PUZZI 64/35E - Page 37

86343360 PUZZI 64/35E 37
Vacuum, 2-Stage
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86005810 57245 8 NUT, 1/4-20 HEX NYLOCK SS
2 86274090 70092 5 SCR, 10-32 X 1.5 PPHMS
3 86233430 81431 2 CLAMP, 2.50 WORM GEAR
4 86010630 87013 16 WASHER, 1/4 X 5/8 FLAT SS
5 86278990 87017 8 WASHER, #8 X 3/8 FLAT
6 86311520 - 1 MANIFOLD, VACUUM, DUAL
7 86312990 - 1 GASKET, VAC MANIFOLD, DUAL
8 86314710 - 8 SCR, 1/4-20 X 5.50 HHCS PLT
9 86317630 - 8 SCR, #8 X 3/4" PPHSMS TYPE AB
10 86318300 - 1 HOSE, VAC, 2.0 ID X 18.5"L
11 86318760 - 2 VAC ASM, 2-STAGE, 120V
- 86135320 140687 - SP BRUSHES SET (120V VAC)
12 86312080 - 2 COVER, VAC MOTOR
13 86312220 - 2 BASE, VAC MOTOR, 2-STAGE
- 86319020 - - VAC HOUSING, 2-STAGE INCLUDES 12, 13
