English 7
brochure "Safety indications for brush
cleaning appliances and spray extrac-
tion appliances".
Figure 1, see cover page
Î Insert the holder for the floor nozzle
(optional) into the appliance and
lock into place.
Figure 2, see cover page
Î Insert the suction hose into the suc-
tion hose connection on the appli-
ance.
Î Insert the coupling of the fresh wa-
ter hose into the fresh water con-
nection of the appliance and lock
into place.
Î Connect the suction hose to bender
of the manual nozzle.
Î Connect the coupling of the fresh
water hose to the bender and lock
into place.
* not included in the delivery
Figure 3, see cover page
Î Mix fresh water and detergent in a
clean container (use the concentra-
tion recommended for the deter-
gent).
몇 Warning
Health risk, risk of damage. Observe
all indications on the detergent used.
Note
Warm water (max. 50°C) will increase
the cleaning effect.
For considerate treatment of the envi-
ronment use detergent economically.
Î Fill detergent solution into the fresh
water reservoir. The fill level must
not exceed the "MAX" mark.
Î Insert dirt water reservoir into the
appliance and attach lid.
Î Insert the plug into the socket.
Figure 4, see cover page
Î Press the suction switch to turn on
the suction turbine.
Î Press the spray switch to turn on
the detergent pump.
몇 Warning
Risk of damage. Check the object to be
cleaned prior to using the appliance in
an inconspicuous place for colour fast-
ness and water resistance.
Figure 5, see cover page
Î Use the lever on the bender to
spray on detergent solution.
Î Run across the surface to be
cleaned in overlapping paths. Pull
the nozzle backwards (do not
push).
Figure 6, see cover page
Î During nozzle changes, the manual
nozzle can be inserted into the
holder for the manual nozzle.
Î If the dirt water reservoir is full,
switch off the suction and spray
switches.
Î Remove the lid.
Start up
Selecting the nozzle
Upholstery, wall rugs,
automobile interior
cleaning
Manual noz-
zle (110 mm)
Carpeting Floor nozzle
(230 mm) *
Stairs Carpet noz-
zle *
Operation
Empty the dirt water reservoir.

Kärcher Puzzi 8/1 C Specifications

General

Type	Drum vacuum
Cleaning type	Wet
Dust capacity	- L
Product color	Black, Grey, Yellow
Dust container type	Bagless
Cord length	7.5 m
Carrying handle(s)	Yes
Maximum area covered	18 m²
Clean water tank capacity	8 L
Dirty water tank capacity	7 L
Airflow	61 l/s
Proper use	Professional
Noise level	- dB
Cleaning surfaces	Carpet, Hard floor
Vacuum air filtering	Water
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Maximum input power	1200 W
Annual energy consumption	- kWh

Weight and Dimensions

Depth	530 mm
Width	330 mm
Height	440 mm
Weight	9800 g
